NIKA-Nylon 3-4 strand ropes are 100% Nylon (Polyamide) ropes fit for applications requiring elasticity and shock absorption properties.
They have very good resistance to abrasion, sunlight, chemicals, and cyclic loading.
When wet they lose approximately 10% of their dry breaking strength which is recovered once dry again.
They are produced according to international standards such as DIN EN ISO 1140, MIL-R-17343, etc. They are user-friendly, flexible, and easy to splice.
| Size (Circ) Inch | Size (Diam) mm | Weight (+/- 5%) Kilos/ 100m | Weight (+/- 5%) Kilos/ 200m | Min. Breaking Load |
|---|---|---|---|---|
| 3/4 | 6 | 2.7 | 5.4 | 0.8 |
| 1 | 8 | 4.5 | 9 | 1.35 |
| 1 1/4 | 10 | 6.5 | 13 | 2.08 |
| 1 1/2 | 12 | 9.5 | 19 | 3 |
| 1 3/4 | 14 | 12.5 | 25 | 4.1 |
| 2 | 16 | 16.5 | 33 | 5.3 |
| 2 1/4 | 18 | 21 | 42 | 6.7 |
| 2 1/2 | 20 | 26 | 52 | 8.3 |
| 2 3/4 | 22 | 31.5 | 63 | 10 |
| 3 | 24 | 35 | 70 | 12 |
| 3 1/4 | 26 | 42 | 84 | 14 |
| 3 1/2 | 28 | 48 | 96 | 15.8 |
| 3 3/4 | 30 | 56 | 112 | 17.8 |
| 4 | 32 | 62 | 124 | 20 |
| 4 1/4 | 34 | 71 | 142 | 22.4 |
| 4 1/2 | 36 | 79.5 | 159 | 24.8 |
| 4 3/4 | 38 | 92 | 184 | 27.4 |
| 5 | 40 | 98 | 196 | 30 |
